Topaz Tz110 FPGAs

The Tz110 FPGA features the high-density, low-power 16 nm Efinix® Quantum® fabric wrapped with an I/O interface in a small footprint package for easy integration. Tz110 FPGAs support industrial printers, machine vision, digital signage and LED walls markets that need low power, a small form factor, and a multitude of I/Os. Tz110 FPGAs:

• Are fabricated on a 16 nm process.
• Have high-voltage I/O (HVIO)—Simple I/O blocks that support the single-ended LVTTL and LVCMOS I/O standards.
• Have high-speed I/O (HSIO)—Complex I/O blocks that support single-ended and differential I/O; LVDS, subLVDS, Mini-LVDS, and RSDS (RX, TX, and bidirectional) up to 1.3 Gbps; and also operate as MIPI lanes at 1.3 Gbps.
• MIPI D-PHY hard IP with speeds up to 2 Gbps
• LPDDR4 PHY (supporting x16 or x32 DQ widths) with memory controller hard IP
• Have device configuration options including a standard SPI and JTAG interfaces.
• Are fully supported by the Efinity® software, an RTL-to-bitstream compiler.

Applications

Industrial printers, machine vision, digital signage and video walls.
